Specifications, Operating specifications network specifications – Rockwell Automation 1747-BSN Backup Scanner Module User Manual
Page 16
Publication 1747-5.38 – September 1999
40071-040-01 (A)
© 1999 Rockwell International. All Rights Reserved. Printed in USA
Specifications
Operating Specifications
Network Specifications
Baud Rate Determination of Maximum Cable Length and Terminating
Resistor Size
DIP switch configuration settings are shown on page 10.
Backplane Current Consumption
800 mA at 5V
Operating Temperature
+32°F to +140°F (0°C to +60°C)
Storage Temperature
-40°F to +185°F (-40C to +85°C)
Humidity
5 to 95% without condensation
Noise Immunity
NEMA Standard ICS 2-230
Agency Certification
(when product or packaging is marked)
UL listed
C-UL listed – Class I, Division 2, Groups A, B, C, D
Temp. Code T3C
CE compliant for all applicable directives
Baud Rate
Maximum Cable Distance
Terminating Resistor Size
57.6K baud
3048 meters (10,000 feet)
150
Ω 1/2 Watt
Brown-Green-Brown-Gold
115.2K baud
1525 meters (5,000 feet)
150
Ω 1/2 Watt
Brown-Green-Brown-Gold
230.4K baud
750 meters (2,500 feet)
82
Ω 1/2 Watt
Gray-Red-Black-Gold
