10 ArmorPOINT 24V DC Very High Speed Counter Modules, Series A
Configure the Very High Speed Counter Module
Parameter Set/Get Description Bytes
1 Set/Get Counter Configuration (see page 11) 1
2 Set/Get Filter Selection (see page 12) 1
3 Set/Get Decimal Position 1
4 Set/Get Active Output Assembly 1
5 Set/Get Time Base Value/PWM Period 2
6 Set/Get Gate Interval 1
7 Set/Get Channel Scalar (see page 12) 1
8 Set/Get Output 0 Ties 1
9 Set/Get Output 1 Ties 1
10 Set/Get Channel Rollover Value 4
11 Set/Get Channel Preset Value 4
12 Set/Get ON Value 1 4
13 Set/Get OFF Value 1 4
14 Set/Get ON Value 2 4
15 Set/Get OFF Value 2 4
16 Set/Get ON Value 3 4
17 Set/Get OFF Value 3 4
18 Set/Get ON Value 4 4
19 Set/Get OFF Value 4 4
20 Set/Get PWM Safe State Value 2
21 Set/Get Counter Control Safe State 1
22 Set/Get Output Control Safe State 1
23 Set/Get Requested Poll Produce Assembly 1
24 Set/Get Requested COS Produce Assembly 1
25 Set/Get Requested Poll Consume Assembly 1
