Rockwell Automation 1769-L32C_L35CR CompactLogix Controller Installation Instructions User Manual
Page 45
1769-L32C, 1769-L35CR CompactLogix Controller 45
Publication
1769-IN070C-EN-P - May 2008
North American temp code
T4A
Replacement battery
1769-BA
Weight, approx.
0.32 kg (0.70 lb)
Programming cable
1747-CP3 or 1756-CP3
Panel mounting screw
torque
(using M4 or #8 screws)
1.1…1.18 N•m (10…16 lb•in)
Wiring category
2 on communication ports
(2)
Wiring connectors
1769-L32C
1 BNC connector
1 NAP (1786-CP cable)
1769-L35CR
2 BNC connectors for
redundant media operation
1 NAP (1786-CP cable)
Isolation voltage
(continuous-voltage
withstand rating)
30V (continuous), Basic Insulation Type
Type tested at 710V DC for 60 s, RS232 to system, CNet to
system, RS232 to CNet, CNet Channel A to CNet channel B
Enclosure Type Rating
None (open-style)
(1)
This specification is know as Power Consumption.
(2)
Use this Conductor Category information for planning conductor routing. See Industrial Automation
Wiring and Grounding Guidelines, publication 1770-4.1.
CompactLogix Controller - 1769-L32C, 1769-L35CR
Attribute
Value
