FLEX I/O 8 Input HART Analog Module 19
Publication 1794-IN108D-EN-P - January 2014
48 Ch3 HART Secondary Value Units Code Ch3 HART Primary Value Units Code
49 Ch3 HART Fourth Value Ch3 HART Tertiary Value Units Code
50 Ch4 HART Field Device Status Ch4 HART Communication Status
51 Reserved Ch4 HART Loop Status
52 Ch4 HART Primary Value
53
54 Ch4 HART Secondary Value
55
56 Ch4 HART Tertiary Value
57
58 Ch4 HART Fourth Value
59
60 Ch4 HART Secondary Value Units Code Ch4 HART Primary Value Units Code
61 Ch4 HART Fourth Value Ch4 HART Tertiary Value Units Code
62 Ch5 HART Field Device Status Ch5 HART Communication Status
63 Reserved Ch5 HART Loop Status
64 Ch5 HART Primary Value
65
66 Ch5 Secondary Value
67
68 Ch5 Tertiary Value
69
70 Ch5 Fourth Value
71
72 Ch5 HART Secondary Value Units Code Ch5 HART Primary Value Units Code
73 Ch5 HART Fourth Value Ch5 HART Tertiary Value Units Code
74 Ch6 HART Field Device Status CH6 HART Communication Status
75 Reserved Ch6 HART Loop Status
76 Ch6 HART Primary Value
77
HART Input Data
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
