16 FLEX I/O 8 Input HART Analog Module
Publication 1794-IN108D-EN-P - January 2014
Digital Filter
6 0 1 1 0 4…20 mA as
√ %
4.00 22.00 0
(0%)
10607
(106.07%)
0.17% of
4...20 mA
7 0 1 1 1 4…20 mA as
unsigned
integer
4.00 20.00 0
(4 mA)
65535
(20 mA)
0.03% of
4...20 mA
8 1 0 0 0 Not assigned
9 1 0 0 1
10 1 0 1 0
11 1 0 1 1 0...20 mA as
A/D count
0.00 22.00 0
(0 mA)
55000
(22 mA)
0.04% of
0...20 mA
12 1 1 0 0 4...20 mA as
%
3.60 21.00 -250
(-2.50%)
10625
(106.25%)
0.16% of
4...20 mA
13 1 1 0 1 4...20 mA as
%
3.00 21.00 -625
(-6.25%)
10625
(106.25%)
0.16% of
4...20 mA
14 1 1 1 0 4...20 mA as
%
2.00 22.00 -1250
(-12.50%)
11250
(112.50%)
0.16% of
4...20 mA
15 1 1 1 1 Not assigned
Digital Filter
frequency Decimal
Value Bits Digital Filter
frequency Decimal
Value Bits
2 1 0 2 1 0
10 9 8 10 9 8
0.5 Hz 7 0 0 0 10 Hz 3 1 0 0
1 Hz 6 0 0 1 Not applicable (1)
(1) Decimal Values 2, 1 and 0 are not applicable. Values will Revert to the last valid configuration (in case
of original start-up this would be default configuration) and set module Diagnostic Status to "2"
configuration failure.
2 1 0 1
2 Hz 5 0 1 0 Not applicable 1 1 1 0
4 Hz 4 0 1 1 Not applicable 0 1 1 1
Data Format - Write Words 2 and 3
Data
Format Bits Format Signal Range User Range Resolution
15 14 13 12
11 10 9 8
7 6 5 4 LO HI LO HI
3 2 1 0
