Compact Combination Fast Analog I/O Module 23
Publication 1769-IN081A-EN-P - February 2007
Specifications
Compact Combination Fast Analog I/O Module - 1769-IF4FXOF2F
Attribute Value
Dimensions (HxWxD), Approx. 118 mm (height) x 87 mm (depth) x 35 mm (width)
Height including mounting tabs is 138 mm (5.43 in.)
4.65 in. (height) x 3.43 in (depth) x 1.38 in (width)
Height including mounting tabs is 138 mm (5.43 in.)
Approximate Shipping Weight
(with carton) 290 g (0.64 lbs.)
Storage Temperature -40 °C to +85 °C (-40 °F to +185 °F)
Operating Temperature 0 °C to +60 °C (32 °F to +140 °F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude 2000 m (6561 ft)
Vibration Operating: 10 to 500 Hz, 5 G, 0.030 in. peak-to-peak
Shock Operating: 30 G, 11 ms panel mounted
(20G, 11 ms DIN rail mounted)
Non-Operating: 40G panel mounted
(30G DIN rail mounted)
Bus Current Draw, max. 220 mA at 5V dc
120 mA at 24V dc
(1)
(1) If the optional 24V dc Class 2 power supply is used, the 24V dc current draw from the bus is 0 mA.
Heat Dissipation 3.39 Total Watts (The Watts per point plus the minimum Watts
with all points energized.)
Module OK LED On: module has power, has passed internal diagnostics, and is
communicating over the bus.
Off: Any of the above is not true.
System Power Supply Distance Rating The module may not be more than 8 modules away from the
system power supply.
Recommended Cable Belden™ 8761 (shielded)
Vendor I.D. Code 1
Product Type Code 10
Product Code 43
Input Words 10
Output Words 4
Configuration Words 42
