Wire Size and Terminal Screw Torque
Each terminal accepts two wires with the following restrictions:.
Configure the 1769-IF4FXOF2F Module
The following I/O memory mapping lets you configure the 1769-IF4FXOF2F
module.
Output Data File
For each module, slot x, words 0 and 1 in the output data file contain the control
program’s directed state of the module’s analog output channels. Word 2 contains
the cancel input channel alarm control bits. Word 3 contains the cancel output
channel clamp control bits.
The bits are defined as follows:
•
SGN = Sign bit in 2’s complement format.
•
CHIx = Cancel High Process Alarm Latch for Input x: Allows each input
high-process-alarm latch to be individually cancelled. NOTE: Cancel = 1.
•
CLIx = Cancel Low Process Alarm Latch for Input x: Allows each input
low-process-alarm latch to be individually cancelled. NOTE: Cancel = 1.
•
CHOx = Cancel High Clamp Alarm Latch for Output x: Allows each output
high-clamp-alarm latch to be individually cancelled. NOTE: Cancel = 1.
•
CLOx = Cancel Low Clamp Alarm Latch for Output x: Allows each output
low-clamp-alarm-latch to be individually cancelled. NOTE: Cancel = 1.
Wire Type Wire Size Terminal Screw
Torque Retaining Screw
Torque
Solid Cu-90°C (194°F) #14…#22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)
Stranded Cu-90°C (194°F) #16…#22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)
Word/Bit 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Word 0 SGN Analog Output Data Channel 0 0 0
Word 1 SGN Analog Output Data Channel 1 0 0
Word 2 0 0 0 0 0 0 0 0 CL
I3 CH
I3 CL
I2 CH
I2 CL
I1 CH
I1 CL
I0 CH
I0
Word 3 0 0 0 0 0 0 0 0 0 0 0 0 CL
O1 CH
O1 CL
O0 CH
O0
