A-2 Specifications
Publication 1784-IN004E-EN-P - April 2005
non-operating shock IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50g
emissions CISPR 11:
Group 1, Class A
ESD immunity IEC 61000-4-2:
6kV contact discharges
8kV air discharges
radiated RF immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 80MHz to 2000MHz
10V/m with 200Hz 50% pulse 100%AM at 900MHz
10V/m with 200Hz 50% pulse 100%AM at 1890MHz
EFT/B immunity IEC 61000-4-4:
+/-2kV at 5kHz on communications ports
surge transient immunity IEC 61000-4-5:
+/-2kV line-earth (CM) on communications ports
conducted RF immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80% AM from 150kHz to 80MHz
enclosure type rating none (open-style)
power requirements In US, this equipment must be powered from UL Listed Information
Technology Equipment or UL Listed Industrial Control Equipment. In
Canada, this equipment must be powered by an SELV source, CSA
Certified Information Technology Equipment, or CSA Certified
Process Control Equipment.
PC: 5V dc, 700mA maximum, Class 2.
The DeviceNet power supply must be compliant with the
requirements for Class 2 as defined in NFPA-70, National Electrical
Code and/or CSA C22.1, Canadian Electrical Code, Part 1.
DeviceNet: +24V dc @90 mA max. Class 2
power dissipation 3.5W
isolation voltage (continuous-voltage
withstand rating) 50V continuous
Tested to withstand 500V for 60 seconds.
wire size 12 AWG (minimum) copper wire
24 AWG (maximum) copper wire
