Install Your FLEX I/O Input Module
Overview
This chapter provides you with pre-installation requirements and instructions
on how to install your FLEX I/O Thermocouple, RTD, and Millivolt Input
module.
Before You Install Your
Module
Before installing your FLEX I/O Thermocouple, RTD, and mV module, you
need to:
• verify that a suitable enclosure is available for installation of the module,
and
• position the keyswitch on the terminal base.
Topic
Page
Before You Install Your Module
Mount the FLEX I/O Module on the Terminal Base Unit
ATTENTION
These modules do not receive primary operational power from the
backplane. 24V DC power must be applied to your module before
installation. If power is not applied, the module position may appear
to the adapter as an empty slot in your chassis.
ATTENTION
If using a Series B product to replace a Series A product, connect a
wire between terminals 39 and 48 on the 1794-TB3G or 1794-TB3GS
terminal base unit. If not connected, the Series B product defaults to
Series B functionality.
