RTD Input Module 2
Publication 1771Ć5.63 - November 1998
EMC Directive
This product is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards,
in whole or in part, documented in a technical construction file:
•
EN 50081-2EMC – Generic Emission Standard,
Part 2 – Industrial Environment
•
EN 50082-2EMC – Generic Immunity Standard,
Part 2 – Industrial Environment
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC
Low Voltage, by applying the safety requirements of EN 61131–2
Programmable Controllers, Part 2 – Equipment Requirements and
Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as these Allen-Bradley
publications:
Publication Publication number
Industrial Automation Wiring and Grounding Guidelines
For Noise Immunity
1770Ć4.1
Guidelines for Handling Lithium Batteries AGĆ5.4
Automation Systems Catalog B111
This equipment is classified as open equipment and must be mounted
in an enclosure during operation to provide safety protection.
The 1771-IR/D module can be used with any 1771 I/O chassis.
Compatibility and data table use is listed below.
C
Use of Data Table Compatibility
Catalog
Number
Input
Output
Read
Block
Write
Block
Addressing
Chassis
S i
Bits
Bits
Block
Words
Block
Words 1/2ĆSlot 1ĆSlot 2ĆSlot
Series
1771ĆIR/D 8 8 8/9 14/15 Yes Yes Yes A, B
A = Compatible with 1771ĆA1, ĆA2, ĆA4 chassis.
B = Compatible with 1771ĆA1B, ĆA2B, ĆA3B, ĆA4B chassis.
Yes = Compatible without restriction.
No = Restricted to complementary module placement.
Do not use this module with Cat. No. 1771-AL PLC-2/20 or 2/30
Local Adapter.
Understand Product
Compatibility
