Connect to the Network Using a Fiber Cable
1. Remove and save the protective caps from the ControlNet daughtercards.
2. Connect the fiber cable connector to the module’s connector.
тюыюшэщчфъщяюсъыщрпуьхъщопыщнюмлпыущкмъыцчюпш
The zipcord uses a duplex cable. Duplex cables use a single cable that contains two
separate fibers, one for transmit and one for receive.
IMPORTANT
To prevent inadvertent reversal of the trunk cable connections
(resulting in incorrect status displays), check the drop cable for a
label indicating the attached cable before you make your
connection.
42821
1
2
