12 ControlNet Daughtercard

Publication 1788-IN005A-EN-P - March 2001

Wiring for the 1786-CP Connector Cable

Daughtercard Performance

Due to wide variation in available host devices, we cannot provide specific
performance capabilities in this document. For information concerning host/
daughtercard performance characteristics, refer to the user manual for the particular
host device.

Connector 1

Connector 2

Wire

Number

Signal

Mnemonic

Signal

Name

Wire
Number

Signal
Mnemonic

Signal
Name

1

ISO-GND

Isolated Ground

1

ISO-GND

Isolated Ground

2

N.C.

No Connection

2

N.C.

No Connection

3

PTTX-H

Transmit Data High

3

PTRX-H

Receive Data High

4

PTTX-L

Transmit Data Low

4

PTRX-L

Receive Data Low

5

PTRX-L

Receive Data Low

5

PTTX-L

Transmit Data Low

6

PTRX-H

Receive Data High

6

PTTX-H

Transmit Data High

7

N.C.

No Connection

7

N.C.

No Connection

8

ISO-GND

Isolated Ground

8

ISO-GND

Isolated Ground
