ControlNet-to-DeviceNet Linking Device 47
Publication 1788-IN052D-EN-P - February 2007
Specifications
CN2DN Linking Device, 1788-CN2DN
Attribute Value
Dimensions (H x W x D),
Approx. 120 x 200 x 87 mm (4 11/16 x 7 7/8 x 3 7/16 in.)
Enclosure Type None (Open-style)
IEC Temp Code T4
Isolation Voltage 30V, Basic Insulation Type
Tested at 720V dc for 60 seconds, between all ports
North American Temp Code T4A
Wiring Category
(1)
(1)
Use this conductor category information for planning conductor routing as described in Industrial
Automation Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on power ports
2 - on communication ports
Wire Size, Power
2.5 mm
2
(14 AWG)… 0.25 mm
2
(22 AWG) solid or stranded
copper wire rated at 75 °C (167 °F) or greater 3/64 inch (1.2
mm) insulation max
Wire Size, DeviceNet Refer to the DeviceNet Media Design and Planning Guide,
publication DNET-UM072, for information specific to your
DeviceNet network.
Wire Size, ControlNet RG6
