10 ArmorPoint I/O Modules with 8 Configurable 24V DC Points
Publication
1738-IN026B-EN-E - February 2010
In RSLogix5000, the default tag will be AdapterName:SlotNumber:O.Data.
The data type is a SINT.
In RSLogix5000, the default tags will be:
• AdapterName:SlotNumber:C.FilterOffOn
• AdapterName:SlotNumber:C.FilterOnOff
Default Data Map – Product Assembly Instance 34
Message Size: 1 Byte
7
6
5
4
3
2
1
0
Data
Pt 07
Pt 06
Pt 05
Pt 04
Pt 03
Pt 02
Pt 01
Pt 00
Where:
Pt = state of the output point
Default Data Map – Product Assembly Instance 103
Message Size: 8 Bytes
7
6
5
4
3
2
1
0
Data [0]
Group Off2On Input filter
Data [1]
Data [2]
Group On2Off Input filter
Data [3]
Data [4]
FltM 7
FltM 6
FltM 5
FltM 4
FltM 3
FltM 2
FltM 1
FltM 0
Data [5]
FltV 7
FltV 6
FltV 5
FltV 4
FltV 3
FltV 2
FltV 1
FltV 0
Data [6]
IdIM 7
IdIM 6
IdIM 5
IdIM 4
IdIM 3
IdIM 2
IdIM 1
IdIM 0
Data [7]
IdIV 7
IdIV 6
IdIV 5
IdIV 4
IdIV 3
IdIV 2
IdIV 1
IdIV 0
Where:
Filter = 0 to 65000 us (0 = default)
Filter = 0 to 65535 us (1000 = default)
FltM = Fault Mode (0 = Fault Value (default), 1 = Hold Last State)
FltV = Fault Value (0 = OFF (default), 1 = ON)
IdlM = Idle Mode (0 = Idle Value (default), 1 = Hold Last State)
IdlV = Idle Value (0 = OFF (default), 1 = ON)
