6–36 Library of Routines OC_GetStatusFile
Publication 1747-6.5.3 June 1998
OC_GetStatusFile OC_GetStatusFile reads a copy of the current scanner system status file into the
STSFILE structure pointed to by stsfil on the scanner.
Syntax:
int OC_GetStatusFile(HANDLE handle, STSFILE *stsfil);
Parameters:
Description:
The status file is updated by the scanner at the end of each I/O scan.
The STSFILE structure is defined as:
typedef struct tagSTSFILE
{
WORD wWordNum[OCSTSFILEWSIZE];
} STSFILE;
The status file is organized by words. The status file uses these classifications to define the data each word
contains:
The status file contains:
Parameter: Description:
handle Must be a valid handle returned from OC_OpenScanner
stsfil Points to the STSFILE structure that contains scanner system status
This classification: Means the data:
status
is used primarily to monitor scanner options or status. This
information is usually not written by the application, except to
clear a function such as a minor error bit.
dynamic configuration
can be written by application to select scanner options while
in Scan mode.
Word/Bit: Classification: Description:
0/0 to 0/4 status
Scanner mode/status
bit 4
bit 3 bit 2bit 1bit 0
1 0 000= (16) download in progress
1 0 001= (17) Idle mode (program)
1 1 110= (30) Scan mode (run)
All other values for bits 0-4 are reserved.
0/5 status
Forces enabled bit
This bit is set if forces have been enabled.
