Publication 1747-6.5.3 June 1988
Chapter
1
Overview
Introduction
This chapter provides an overview of the 1746 I/O PCI Interface and the API
software. This chapter also describes how to install the API.
You should have one of the following APIs:
•
API for DOS (catalog number 1747-PCIDOS)
•
API for Windows NT (catalog number 1747-PCINT)
The API software license agreement allows you to freely distribute the executable.
Relationship to
the Open
Controller
The API software for the 1746 I/O PCI Interface is compatible with the API for the
1747 Open Controller. The sample code and header files contain comments and
functions that are supported by the Open Controller but not supported by the 1746
I/O PCI Interface. The following table lists the differences between the Open
Controller and the 1746 I/O PCI Interface.
Important: All references to Open Controller in the example code or header files
apply to the 1746 I/O PCI Interface.
Open Controller 1746 I/O PCI Interface
User assigns interrupts and memory allocation. 1747-PCIS(2) is a plug-and-play card.
Watchdog can reset the entire system. Watchdog cannot reset entire system.
Contains OC_ReadRtcSRAM. Function not supported.
Contains OC_WriteRtcSRAM. Function not supported.
Does not provide access to user SRAM. Provides access to user SRAM.
