Configuring I/O Modules
5–5
Publication 1747-6.5.3 June 1998
Module Name:
a
Description:
Class:
Mix:
b
Type:
1746-IO4
2-Input 100/120 V ac 2-Output [RLY]
0
8
0
1746-IO8
4-Input 100/120 V ac 4-Output [RLY]
0
11
0
1746-IO12
6-Input 100/120 V ac 6-Output [RLY]
0
15
0
1746-INT4
4 thermocouples, isolated
1
35
15
1746sc-INO4VI
Spectrum Controls, 4 Analog Outputs
1
35
19
1746sc-INI4VI
Spectrum Controls, 4 Analog Inputs
1
35
20
1746sc-INO4I
Spectrum Controls, 4 Analog Outputs
1
35
21
1746sc-INI4I
Spectrum Controls, 4 Analog Inputs
1
35
22
1746-NI4
4 Channel Analog Input
1
44
1
1746-NI8
8 Analog Inputs
1
35
26
1746-NI8
8 Analog Inputs
3
127
26
1746-NIO4I
Analog Comb. 2 In & 2 Current Out
1
32
1
1746-NIO4V
Analog Comb. 2 In & 2 Voltage Out
1
32
2
1746-FIO4I
Fast Analog Comb 2 In & 2 Current Out
1
32
24
1746-FIO4V
Fast Analog Comb 2 In & 2 Voltage Out
1
32
18
1746-NO4I
4 Channel Analog Current Output
1
54
1
1746-NO4V
4 Channel Analog Voltage Output
1
54
2
1746-NT4
4 Channel Thermocouple Input Module
1
35
10
1746sc-NT8
Spectrum Controls, 4 Analog inputs isolated
1
35
33
1746-NR4
4 Channel RTD/Resistance Input Module
1
35
13
1746-HSCE
High Speed Counter/Encoder
3
127
5
1746-HS
Single Axis Motion Controller
1
33
3
1746-HSRV
SLC Servo Single AX MC
3
101
14
1746-HSTP1
Stepper Controller Module
1
35
12
1746-BAS1
c
BASIC Module - 5/01 Configuration
1
35
6
1746-BAS2
c
BASIC Module - 5/02 Configuration
4
131
6
1746-QS
Synchronized Axes
4
136
27
1746-QV
Open Loop Velocity
4
131
15
1747-DCM1
c
Direct Commun. Module (1/4 RACK)
1
32
25
1747-DCM2
c
Direct Commun. Module (1/2 RACK)
1
33
25
1747-DCM3
c
Direct Commun. Module (3/4 RACK)
1
34
25
1747-DCM4
c
Direct Commun. Module (FULL RACK)
1
35
25
1747-MNET
Module Interface
4
158
11
1747-SDN
DeviceNet Scanner
4
136
6
1747-SN
Remote I/O Scanner
4
136
8
1747-DSN1
c
Distributed I/O Scanner - 7 Blks
1
35
7
1747-DSN2
c
Distributed I/O Scanner - 30 Blks
4
136
7
1747-KE1
c
Interface Module, Series A
1
42
9
1747-KE2
c
Interface Module, Series B
1
35
9
a.The module names shown in this table correspond to those used by the OC_GetIOConfiguration and
OC_CreateIOConfiguration functions.
b.The mix code for a module is composed of one byte field. The upper 3 bits represent the class of the
module, and the lower 5 bits represent the I/O mix of the module.
c.Some modules can have multiple configurations. To distinguish between different configurations of the
same module, a single digit is appended to the module name.
