Rockwell Automation 1395 Node Adapter Board User Manual
Page 40
Chapter 3
Functional Description
3-28
Drive System Reset
This function causes the Drive to do a “warm boot restart”. Any data in
Drive memory at the time the command is issued is erased and is not saved
in EEPROM.
PLC Block Transfer Data –
BTW Instruction Length: 4
BTW Message Structure –
Message Header Information:
Word 1: 0
Word 2: 0
Function Code, Word 3: 1539
Write Message Length, Word 4: 8 bytes
WORD
BTW
1
2
3
4
0
0
1539
8
Message Operation – The DRIVE SYSTEM RESET function causes the
Drive to reboot all processors. This is the same sequence that the Drive
goes through when power is first applied.
IMPORTANT: Any parameter data or configuration links that were not
stored in EEPROM prior to the Drive receiving this command will be
erased.
This BTW function requires the message header only. Ignore any data
returns.
