Chapter 2, Installation, System components – Rockwell Automation 1608M MegaDySC User Manual, 800 Amp - 208V User Manual
Page 7: Chapter

Rockwell Automation Publication 1608M-UM003A-EN-P - December 2013
7
Chapter
2
Installation
System Components
The Standard Run (SR) MegaDySC system consists of two enclosures including
one 800A MegaDySC Module and one Automatic Bypass Switchboard. The
Extended Run (ER) MegaDySC system consists of three enclosures including
one 800A MegaDySC Module, one Extended Run (ER) Module and one
Automatic Bypass Switchboard. The enclosures are shipped separately and must
be mechanically and electrically interconnected at the time of installation.
The 800A MegaDySC Module houses the static bypass and voltage sag-
correction electronics. The ER Module houses the ER energy storage capacitors.
The Automatic Bypass Switchboard houses the maintenance bypass circuit
breaker (CBB), the MegaDySC input (CBI) and output (CBO) circuit breakers,
automatic controls and the i-Sense® voltage-monitoring sensor.
This document applies only to the following MegaDySC system models.
Catalog Number
Current
Rating
Voltage Rating
3 / 4 Wire
SR / ER
1608M-800A208V3S2S03
800 A
208V
3
SR
1608M-800A208V4S2S03
800 A
208V
4
SR
1608M-800A208V3E2S03
800 A
208V
3
ER
1608M-800A208V4E2S03
800 A
208V
4
ER
