Chapter 1 PowerMonitor W250 Unit Overview
PowerMonitor W250 Data Overview
The PowerMonitor W250 unit sends data to the wireless receiver periodically.
The meter data is split into three sections:
• Cumulative Energy Consumption Metering Data: The power monitor
transmits accumulated real, reactive, and apparent energy, per-phase and
total, once per minute. The transmission is accompanied with the time
stamp of the most recent reading.
• Interval Metering Data: The power monitor sends, at the end of the user-
selected interval, a time-stamped record of the following data: real,
reactive, and apparent energy per phase and sum; minimum voltage per
phase and maximum current per phase during recording interval;
frequency.
• Node Identification, Configuration, and Status: Node configuration and
version; recording interval time setup, command and status word.
PowerMonitor W250 Model Description
The following table lists the available models of the PowerMonitor W250 unit.
Table 2 - Model Description
Cat. No. Description Current
Rating (A) Max
Voltage
(1)
Delta/Wye Current
Sensing Model
Code
1425-D1002-MOD PowerMonitor Wireless, 100A, 300V Delta 100 300 Delta, 3 W CT 111
1425-D1002-MOD-480 PowerMonitor Wireless, 100A, 480V Delta 100 480 Delta, 3 W Rogowski Coil 111
1425-W1003-MOD PowerMonitor Wireless, 100A, 300V Wye 100 300 Wye, 4 W CT 000
1425-D2002-MOD PowerMonitor Wireless, 200A, 300V Delta 200 300 Delta, 3 W CT 111
1425-W2003-MOD PowerMonitor Wireless, 200A, 300V Wye 200 300 Wye, 4 W CT 000
1425-D5002-MOD PowerMonitor Wireless, 500A, 300V Delta 500 300 Delta, 3 W CT 111
1425-D5002-MOD-480 PowerMonitor Wireless, 500A, 480V Delta 500 480 Delta, 3 W Rogowski Coil 111
1425-W5003-MOD PowerMonitor Wireless, 500A, 300V Wye 500 300 Wye, 4 W CT 000
1425-D10002-MOD PowerMonitor Wireless, 1000A, 300V Delta 1000 300 Delta, 3 W CT 111
1425-W10003-MOD PowerMonitor Wireless, 1000A, 300V Wye 1000 300 Wye, 4 W CT 000
1425-D20002-MOD PowerMonitor Wireless, 2000A, 300V Delta 2000 300 Delta, 3 W CT 111
1425-D20002-MOD-480 PowerMonitor Wireless, 2000A, 480V Delta 2000 480 Delta, 3 W Rogowski Coil 111
1425-W20003-MOD PowerMonitor Wireless, 2000A, 300V Wye 2000 300 Wye, 4 W CT 000
(1) Maximum voltage on sensing terminals must not exceed the following:
a.300V Delta, 3 W: 300V AC line-to-line maximum
b.300V Wye, 4 W: 300V AC line-to-neutral maximum
c.480V Delta, 3 W: 520V AC line-to-line, 300V AC line-to-neutral maximum
