All parameters are specified at 24V, 80A output current, 25ªC ambient and after a 5 minutes run-in time, unless noted otherwise.
Rockwell Automation Publication 1606-RM011A-EN-P — February 2014 9
Bulletin 1606 Switched Mode Power Supplies
9. EMC
The redundancy module is suitable for applications in industrial environment as well as in residential, commercial and
light industry environments without any restriction. A detailed EMC report is available upon request.
EMC Immunity According generic standards: EN 61000-6-1 and EN 61000-6-2
Electrostatic discharge EN 61000-4-2 Contact discharge
Air discharge 8kV
15kV Criterion A
Criterion A
Electromagnetic RF field EN 61000-4-3 80MHz-2.7GHz 20V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input lines
Output lines 2kV
2kV Criterion A
Criterion A
Surge voltage on input
lines EN 61000-4-5 + -
+/- Chassis ground 500V
1kV Criterion A
Criterion A
Surge voltage on output
lines EN 61000-4-5 + -
+/- Chassis ground 500V
1kV Criterion A
Criterion A
Conducted disturbance EN 61000-4-6 0.15-80MHz 20V Criterion A
Power-frequency magnetic
field *) EN 61000-4-8 50Hz 30A/m Criterion A
Criteria:
A: Redundancy module shows normal operation behavior within the defined limits.
Notes:
*) A test is not applicable according to EN 61000-6-2, since the device does not contain components susceptible to magnetic fields, e.g. hall
elements, electrodynamic microphones, etc.
EMC Emission According generic standards: EN 61000-6-3 and EN 61000-6-4
Conducted emission IEC/CISPR 16-1-2, IEC/CISPR 16-2-1 limits for DC power ports according
EN 61000-6-3 fulfilled
*)
Radiated emission EN 55011, EN 55022 Class B
This device complies with FCC Part 15 rules.
Operation is subjected to following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
*) For information only, not mandatory for EN 61000-6-3. Provided that power sources connected on the inputs fulfill the requirements as well.
Switching frequency The internal auxiliary supply is generated with a boost converter.
The switching frequency is typ. 16kHz.
