GuardShield™ Safety Light Curtain User Manual
35
R
Original instructions
Corner Mirror for Multi-Sided Guarding
Specially constructed glass mirrors for 2- and 3-sided safeguarding applications.
Note: Each mirror reduces maximum scan range by 10% per mirror. Each corner mirror suppled with two end-cap mounting brackets.
¿ = J or K; Œ = D or R;  = A or D
Mounting Stand—440L-AMSTD Laser Alignment Tool
GuardShield Light Curtain Cat. No. Narrow Mirror Short-Range 0…4 m Cat. No. Wide Mirror Long-Range 4…15 m Cat. No.
440L-P4 ¿0160YŒ
440L-P2K 0160YD 440L-AM0750300 440L-AM1250300
440L-P4 ¿0320YŒ
440L-P2K 0320YD 440L-AM0750450 440L-AM1250450
440L-P4 ¿0480YŒ
440L-P2K 0480YD
440L-P4A2500YD
440L-AM0750600 440L-AM1250600
440L-P4 ¿0640YŒ
440L-P2K 0640YD 440L-AM0750750 440L-AM1250750
440L-P4 ¿0800YŒ
440L-P2K 0800YD 440L-AM0750900 440L-AM1250900
440L-P4 ¿0960YŒ
440L-P2K 0960YD
440L-P4A3400YD
440L-AM0751050 440L-AM1251050
440L-P4 ¿1120YŒ
440L-P2K 1120YD 440L-AM0751200 440L-AM1251200
440L-P4 ¿1280YŒ
440L-P2K 1280YD 440L-AM0751350 440L-AM1251350
440L-P4 ¿1440YŒ
440L-P2K 1440YD 440L-AM0751500 440L-AM1251500
440L-P4 ¿1600YŒ
440L-P2K 1600YD 440L-AM0751650 440L-AM1251650
440L-P4 ¿1760YŒ
440L-P2K 1760YD 440L-AM0751800 440L-AM1251800
66.8
(2.63)
19.05
(0.75)
62.48
(2.46)
12.19
(0.48)
4.0
(0.15)
17.78
(0.70)
35.56
(1.4)
44.45
(1.75)
4.29 (0.169) hole dia.
81° x 2.66 (0.105)
Countersink
1828.8
(72)
63.5 (2.5)
25.4
(1.0)
12.7 (0.5) Dia. 4X
6.35
(0.25)
6.35
(0.25)
76.2
(3.0)
19.05 (0.75)
11.1 (7/16) Dia.
25.4
(1.0)
76.2
(3.0) 63.5
(2.5)
304.8
(12)
M10 x 1.5 mm
Class 6g thru 4 pl
381.0 (15)
GuardShield LAT Bracket
—
440L-AF6109
Laser Alignment Tool (LAT)
—
440L-ALAT
Pedestal floor stand
