GuardShield™ Safety Light Curtain User Manual
31
Original instructions
Note: If the Transmitter’s configuration needs to be changed
from the factory settings, set the DIP switches in the
transmitter and follow the standard teach process
Remote Teach Procedure
1. Position object in the GuardShield sensing field, assure that the
synchronization beam is not obstructed
2. Turn keyswitch to the configure position. The receiver’s red LED
will be flashing and the yellow blanking LED will be illuminated.
3. Turn and hold keyswitch in the Teach position
4. The GuardShield receiver’s yellow blanking LED will begin
flashing.
5. When the yellow blanking LED stops flashing, release the
keyswitch to the configure position within two seconds .
6. The GuardShield receiver’s yellow blanking LED will flash three
times to confirm that the new fixed blanking configuration has
been set.
7. Turn the keyswitch to the RUN position, the green LED on the
GuardShield receiver will illuminate.
8. Using the supplied test rod, confirm the fixed blanking area and any
other settings are configured as expected.
It is possible to configure and activate both fixed and one or two beam
floating blanking on the GuardShield light curtain.
NOTE: Once the GuardShield is configured by changing factory DIP
switch positions and performing the Teach function, the GuardShield
will be reconfigured. Any future Teach procedure will only change the
configuration of the fixed blanking area.
Remote Teach System
Remote Teach System Component Parts
IMPORTANT
After teaching the GuardShield a new
configuration, confirm that the configuration
that was expected to be configured has actually
been configured.
IMPORTANT
Fixed blanking creates a “hole” in the detection
area of the GuardShield. It is necessary to assure
that access to the hazard being protected
against is prevented by means of barrier
guarding. It should not be possible to access
the hazard through the fixed blanked area.
Cat. No. Description
440L-S4J0160YR
GuardShield Remote Teach system, 160 mm protective height 14 mm
resolution
440L-S4J0320YR
GuardShield Remote Teach system, 320 mm protective height 14 mm
resolution
440L-S4J0480YR
GuardShield Remote Teach system, 480 mm protective height 14 mm
resolution
440L-S4J0640YR
GuardShield Remote Teach system, 640 mm protective height 14 mm
resolution
440L-S4J0800YR
GuardShield Remote Teach system, 800 mm protective height 14 mm
resolution
440L-S4J0960YR
GuardShield Remote Teach system, 960mm protective height 14 mm
resolution
440L-S4J1120YR
GuardShield Remote Teach system, 1120 mm protective height 14 mm
resolution
440L-S4J1280YR
GuardShield Remote Teach system, 1280 mm protective height 14 mm
resolution
440L-S4J1440YR
GuardShield Remote Teach system, 1440 mm protective height 14 mm
resolution
440L-S4J1600YR
GuardShield Remote Teach system, 1600 mm protective height 14 mm
resolution
440L-S4J1760YR
GuardShield Remote Teach system, 1760 mm protective height 14 mm
resolution
440L-S4K0160YR
GuardShield Remote Teach system, 160 mm protective height 30 mm
resolution
440L-S4K0320YR
GuardShield Remote Teach system, 320 mm protective height 30 mm
resolution
440L-S4K0480YR
GuardShield Remote Teach system, 480 mm protective height 30 mm
resolution
440L-S4K0640YR
GuardShield Remote Teach system, 640 mm protective height 30 mm
resolution
440L-S4K0800YR
GuardShield Remote Teach system, 800 mm protective height 30 mm
resolution
440L-S4K0960YR
GuardShield Remote Teach system, 960mm protective height 30 mm
resolution
440L-S4K1120YR
GuardShield Remote Teach system, 1120 mm protective height 30 mm
resolution
440L-S4K1280YR
GuardShield Remote Teach system, 1280 mm protective height 30 mm
resolution
440L-S4K1440YR
GuardShield Remote Teach system, 1440 mm protective height 30 mm
resolution
440L-S4K1600YR
GuardShield Remote Teach system, 1600 mm protective height 30 mm
resolution
440L-S4K1760YR
GuardShield Remote Teach system, 1760 mm protective height 30 mm
resolution
Catalog Number Description
800F-AKR3825 Replacement Key
440L-M8600 Remote Teach Box
889D-F4ACDM-2 Two meter patchcord
