Profibus identity, Identification and maintenance (i&m) – Rockwell Automation 193-EPRB Profibus Side Mount Module for the E1 Plus Overload Relay User Manual User Manual
Page 37

Publication 193-UM010A-EN-P – January 2008
PROFIBUS Information B-3
PROFIBUS Identity
The module has the following identity on PROFIBUS:
Identification and Maintenance (I&M)
Identification & Maintenance (I&M) provides a standard way of gathering information about an
I/O device. The intention is to help the end-user in maintenance of the product.
The module features the following I&M records:
PI Identification Number
0x0AC7
Vendor Name
Allen-Bradley
Model Name
"193-EPRB"
Table B.6 IM0 Record
Information
Size
Default Value
Manufacturer ID
2 octets
0x0002
Order ID
20 octets
193-EPRB
Serial Number
16 octets
(assigned during manufacturing)
Hardware Revision
2 octets
(assigned during manufacturing)
Software Revision
4 octets
(assigned during manufacturing)
Revision Counter
2 octets
0x0000
Profile ID
2 octets
0xF600
Profile Specific Type
2 octets
0xF600
IM Version
2 octets
0x0101
IM Supported
2 octets
0x001E
Table B.7 IM1 Record
Information
Size
Default Value
Tag Function
32 octets
Blank (0x20)
Tag Location
22 octets
Blank (0x20)
Table B.8 IM2 Record
Information
Size
Default Value
Installation Date
16 octets
Blank (0x20)
Table B.9 IM3 Record
Information
Size
Default Value
Descriptor
54 octets
Blank (0x20)
