Publication 193-UM010A-EN-P – January 2008
3-4 PROFIBUS Configuration
Resetting to the Factory Default Values
Parameter 25, Set to Defaults, allows the installer to reset all parameter settings (including trip
logs) to the factory default values.
Parameter Group Listing
The 193-EPRB PROFIBUS Module contains six parameter groups:
Monitor Group
IMPORTANT
Resetting to factory default values also resets the node address of the
PROFIBUS module to its default value of 126.
Table 3.3 Parameter Groups
Monitor parameters Advanced Setup Reset/Lock I/O Setup Trip History PROFIBUS Setup
1 Average %FLA 8 Trip Enable 19 Trip Reset 22 OutA Pr FltState 30 Trip Log 0 35 SSA Node Address
2%Therm Utilized 9 Warning Enable 20 Program Lock 23 OutA Pr FltValue 31 Trip Log 1
3 Trip Status 10 Single/Three Ph 21 Set to Defaults 24 OutA Pb FltState 32 Trip Log 2
4 Warning Status 11 OL Reset Mode 25 OutA Pb FltValue 33 Trip Log 3
5 Device Status 12 OL Warning Level 26 OutA Pb IdlState 34 Trip Log 4
6 Firmware Revision 13 Jam Inhibit Time 27 OutA Pb IdlValue
7 Serial Number 14 Jam Trip Delay 28 IN1 Assignment
15 Jam Trip Level 29 IN2 Assignment
16 Jam Warn Level
17 UL Inhibit Time
18 UL Warn Level
Average %FLA Index No. 1
This parameter reports the average motor current. The value is
reported as a percentage of motor rated current (dial setting on
the E1 Plus Overload Relay), and is reported in increments of 5. Access Rule Read
Size 2 bytes
Group Monitor
Units %FLA
Min. Value 0
Max. Value 1275
Default Value None
% Therm Utilized Index No. 2
This parameter reports the percent thermal utilization of the
connected motor. Access Rule Read
Size 1 byte
Group Monitor
Units %
Min. Value 0
Max. Value 100
Default Value None
