Publication 193-UM010A-EN-P – January 2008
PROFIBUS Configuration 3-7
Warning Enable Index No. 9
This parameter allows the installer to enable or
disable the warning functions separately. All
warning functions are disabled from the
factory.
1 = Enabled
0 = Disabled Access Rule Read/Write
Size 2 bytes
Group Advanced Setup
Units —
Min. Value 0000000000000000
Max. Value 0000000001101101
Default Value 0000000000000000
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Overload
X Not Used
X Jam
X Underload
X Not Used
X Comm Fault
X Comm Idle
X X X X X X X X X Not Used
Single/Three Ph Index No. 10
This parameter configures the PROFIBUS Module for single-
or three-phase application. This parameter should be set to
“Single Phase" when Bulletin 193S or 592S devices are
employed. Access Rule Read/Write
Size 1 byte
Group Advanced Setup
Units —
Min. Value 0 = Single-Phase
Max. Value 1 = Three-Phase
Default Value 1
OL Reset Mode Index No. 11
This parameter defines whether a trip can be automatically
or manually reset. This setting overrides the E1 Plus DIP
switch adjustment while the PROFIBUS Module is powered.
Note, however, that the E1 Plus manual reset button,
accessible at the front, is always active. Access Rule Read/Write
Size 1 byte
Group Advanced Setup
Units —
Min. Value 0 = Manual
Max. Value 1 = Automatic
Default Value 0
OL Warning Level Index No. 12
This parameter sets the overload warning level. Access Rule Read/Write
Size 1 byte
Group Advanced Setup
Units % Thermal Utilization
Min. Value 0
Max. Value 100
Default Value 90
