Rockwell Automation 193-EPRB Profibus Side Mount Module for the E1 Plus Overload Relay User Manual - Manual (Page 36)

Publication 193-UM010A-EN-P – January 2008
B-2 PROFIBUS Information
scaling. The GSD file for the E1 Plus PROFIBUS Module is available from the Internet at
www.ab.com/networks/gsd/.
Set Slave Address
The PROFIBUS Module supports the Set Slave Address (SSA) service, which can be used to
specify the node address from the PROFIBUS Master.
If successful, the new node address will be stored in non volatile memory, replacing the previous
value of parameter 35, SSA Node Address.
NOTE: This service will be rejected if a previous SSA service request has specified that no
further changes should be allowed, or if the PROFIBUS Module is in Data Exchange.
Supported Baud Rates
The PROFIBUS Module detects the baud rate automatically, and supports all standard baud
rates.
Supported baud rates:
• 9.6kbps
• 19.2kbps
• 45.45kbps
• 93.75kbps
• 187.5kbps
• 500kbps
• 1.5Mbps
• 3Mbps
• 5Mbps
• 12Mbps
