GuardShield™ Safe 4 Safety Light Curtain User Manual
32
R
Original instructions
Safe 4 Specials Catalog Numbers
Catalog Number
Protective
Height A
(mm)*
Total
Length B
(mm)*
Protective
Height C
(mm)*
Total
Length D
(mm)*
Response
Time t
R
(ms)
Max
Range
(m)
Resolution
(mm)
Weight per
Pair (kg)
ILAS
Cascaded
(Separate
Controller)
Comments
Safe 4 without ILAS 14mm - 9m pair
445L-103000-0189
120
240
—
—
10.5
9
14
2.0
without
No
445L-103000-0044
240
360
—
—
15.8
9
14
2.2
without
No
445L-103000-0076
360
480
—
—
21.1
9
14
2.6
without
No
445L-103000-0130
480
600
—
—
26.3
9
14
2.9
without
No
445L-103000-0036
600
720
—
—
31.6
9
14
3.4
without
No
445L-103000-0157
720
840
—
—
36.9
9
14
3.9
without
No
445L-103000-0153
840
960
—
—
42.2
9
14
4.5
without
No
445L-103000-0140
960
1080
—
—
47.5
9
14
4.9
without
No
445L-103000-0136
1080
1200
—
—
52.8
9
14
5.3
without
No
445L-103000-0195
1200
1320
—
—
58.1
9
14
5.6
without
No
445L-103000-0099
1320
1440
—
—
63.4
9
14
5.9
without
No
445L-103000-0196
1440
1560
—
—
68.7
9
14
6.3
without
No
445L-103000-0164
1560
1680
—
—
74.0
9
14
7.0
without
No
Safe 4 without ILA 30mm - 18m pair
445L-103000-0034
360
480
—
—
13.1
18
30
2.6
without
No
445L-103000-0139
480
600
—
—
15.8
18
30
3.0
without
No
445L-103000-0193
840
960
—
—
23.7
18
30
4.4
without
No
445L-103000-0118
1800
1920
—
—
44.9
18
30
7.3
without
No
Safe 4 with separate controller (Not for new application)
445L-103001-1024
0
120
120
170
10.5 ms
9 m
14 mm
2.8 kg
with
Sep. ctrl.
445L-103001-0038
0
120
240
290
15.8 ms
9 m
14 mm
3.3 kg
with
Sep. ctrl.
445L-103001-0033
0
120
360
410
21.1 ms
9 m
14 mm
3.1 kg
with
Sep. ctrl.
445L-103001-0009
0
120
480
530
26.3 ms
9 m
14 mm
3.6 kg
with
Sep. ctrl.
445L-103001-0002
0
120
840
890
42.2 ms
9 m
14 mm
5.4 kg
with
Sep. ctrl.
445L-103001-0012
0
120
1080
1130
52.8 ms
9 m
14 mm
6.2 kg
with
Sep. ctrl.
445L-103001-0228
0
120
1680
1730
79.3 ms
9 m
14 mm
7.1 kg
with
Sep. ctrl.
445L-103001-0229
0
120
1920
1970
89.9 ms
9 m
14 mm
8.1 kg
with
Sep. ctrl.
445L-103001-0118
0
120
120
120
10.5 ms
9 m
14 mm
2.7 kg
without
Sep. ctrl.
445L-103001-0105
0
120
240
240
15.8 ms
9 m
14 mm
3.2 kg
without
Sep. ctrl.
445L-103001-0122
0
120
360
360
21.1 ms
9 m
14 mm
3.6 kg
without
Sep. ctrl.
445L-103001-0117
0
120
480
480
26.3 ms
9 m
14 mm
4.0 kg
without
Sep. ctrl.
445L-103001-0014
0
120
600
600
31.6 ms
9 m
14 mm
4.4 kg
without
Sep. ctrl.
445L-103001-0035
0
120
720
720
36.9 ms
9 m
14 mm
4.8 kg
without
Sep. ctrl.
445L-103001-1020
0
120
840
840
42.2 ms
9 m
14 mm
5.3 kg
without
Sep. ctrl.
445L-103001-0112
0
120
960
960
47.5 ms
9 m
14 mm
5.7 kg
without
Sep. ctrl.
445L-103001-1021
0
120
1440
1440
68.7 ms
9 m
14 mm
7.3 kg
without
Sep. ctrl.
445L-103001-1023
0
120
120
120
10.5 ms
9 m
14 mm
3.0 kg
without
Sep. ctrl.
445L-103001-1025
0
120
240
290
10.5 ms
18 m
30 mm
3.1 kg
with
Sep. ctrl.
445L-103001-1026
0
120
480
530
15.8 ms
18 m
30 mm
4.1 kg
with
Sep. ctrl.
445L-103001-0017
0
120
1080
1130
29.1 ms
18 m
30 mm
6.5 kg
with
Sep. ctrl.
445L-103001-0094
0
120
1440
1490
36.9 ms
18 m
30 mm
7.9 kg
with
Sep. ctrl.
445L-103001-1022
0
120
120
120
7.8 ms
18 m
30 mm
2.7 kg
without
Sep, ctrl.
