GuardShield™ Safe 4 Safety Light Curtain User Manual
22
R
Original instructions
Dimensional Drawings [mm (in.)]
System with integrated controller
Figure 20: The profile length for systems without ILAS is reduced for 2 x 25 mm
Type
A
Protective Height
[mm (in.)]
B
Profile Length
[mm (in.)]
445L-P4
0120YD
120 (4.7)
290 (11.4)
445L-P4
0240YD
240 (9.4)
410 (16.1)
445L-P4
0360YD
360 (14.2)
530 (20.9)
445L-P4
0480YD
480 (18.9)
650 (25.6)
445L-P4
0600YD
600 (23.6)
771 (30.4)
445L-P4
0720YD
720 (28.3)
891 (35.1)
445L-P4
0840YD
840 (33.1)
1011 (39.8)
445L-P4
0960YD
960 (37.8)
1131 (44.3)
445L-P4
1080YD
1080 (42.5)
1252 (49.3)
445L-P4
1200YD
1200 (47.2)
1372 (54.0)
445L-P4
1320YD
1320 (52)
1492 ( 58.7)
445L-P4
1440YD
1440 (56.7)
1612 (63.5)
445L-P4
1560YD
1560 (61.4)
1733 (68.2)
445L-P4
1680YD
1680 (66.1)
1853 (72.9)
445L-P4
1800YD
1800 (70.9)
1973 (77.6)
445L-P4
1920YD
1920 (75.6)
2093 (82.3)
For 14 mm resolution replace with an "L."
For 30 mm resolution replace with an "S." (0…18 m)
For 30 mm resolution replace with an "X." (5…30 m)
20
(0.79)
10
(0.39)
30
(1.18)
30
(1.18)
40
(1.56)
3
(0.12)
25
(0.98)
14.75
(0.58)
alignment
module
laser
A
protection length
B
profile length according to table
145
(5.71)
14.75
(0.58)
35
(1.38)
alignment
module
laser
alignment
module
laser
alignment
module
laser
