GuardShield™ Safe 4 Safety Light Curtain User Manual
27
Original instructions
Appendix
GuardShield Safe4 Specials—for existing
customers
Safety Light Curtain Systems
Content
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Systems without an Integrated Laser Alignment System (ILAS)
27
Systems with Connector Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cascaded Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Systems with Separated Controller . . . . . . . . . . . . . . . . . . . . . . . 29
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cascaded Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
System with Integrated Controller . . . . . . . . . . . . . . . . . . . . . . . 31
Special Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Part List Safe 4 Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Introduction
In addition to the GuardShield Safe 4 manual this appendix shows
some special systems e.g.:
• GuardShield Safe 4 without laser alignment system (ILAS)
• Systems with a hard-wired connection end cap
• Cascaded systems
• Systems with separated controller
• Other special systems
Systems without an Integrated Laser Alignment
System (ILAS)
The systems mentioned in the table below are not equipped with
an integrated laser alignment (ILAS) system. So the profile length
is reduced by 25 mm on each side of the protective field (see
Figure 22).
GuardShield Safe 4 Systems without Laser Alignment
Cascaded GuardShield Safe 4 Systems
Sensor Pair
Resolution
[mm (in.)]
Protective Heights
[mm (in.)]
Range
[m (ft.)]
445L-103000-0189
14 (0.55)
120 (4.7)
9 (29.5)
445L-103000-0044
14 (0.55)
240 (9.5)
9 (29.5)
445L-103000-0076
14 (0.55)
360 (14.2)
9 (29.5)
445L-103000-0130
14 (0.55)
480 (18.9)
9 (29.5)
445L-103000-0036
14 (0.55)
600 (23.6)
9 (29.5)
445L-103000-0157
14 (0.55)
720 (28.4)
9 (29.5)
445L-103000-0153
14 (0.55)
840 (33.1)
9 (29.5)
445L-103000-0140
14 (0.55)
960 (37.8)
9 (29.5)
445L-103000-0136
14 (0.55)
1080 (42.5)
9 (29.5)
445L-103000-0195
14 (0.55)
1200 (47.2)
9 (29.5)
445L-103000-0196
14 (0.55)
1440 (56.7)
9 (29.5)
445L-103000-0164
14 (0.55)
1560 (61.4)
9 (29.5)
445L-103000-0034
30 (1.18)
360 (14.2)
18 (59)
445L-103000-0139
30 (1.18)
480 (18.9)
18 (59)
445L-103000-0193
30 (1.18)
840 (33.1)
18 (59)
445L-103001-0199
30 (1.18)
1560 / 1320
(61.4 / 52)
445L-103001-0057
14 (0.55)
840 / 240
(33.1 / 9.5)
445L-103001-0121
14 (0.55)
600 / 120
(23.6 / 4.7)
445L-103001-0163
14 (0.55)
120 [120 + 240]
(4.7 [4.7 + 9.5])
