Installing Bulletin 500LC Lighting Contactors 2
Publication 500LC–IN001A–EN–P May 2005
Ratings
Bulletin 500LC Lighting Contactors are rated for 20 amps lighting
loads and 30 amps general purpose. They are UL508 Listed, CSA
Certified, and are available in 2–...12–pole single throw double
break and 2–...6–pole normally open and normally closed
configurations. Control voltages are from 120...480V AC. See
Tables A, B, and C for contact ratings.
Table A – Maximum AC Voltage and Amp. Ratings
For Bulletin 500LC Main Contacts (open or closed)
Amperes
Poles to Load
Load Type
Amperes
Continuous 1 for 1 ø
2 for 1 ø
3 for 3 ø
Tungsten 20 250V AC 250V AC
Ballast 20 347V AC 600V AC
General 30 347V AC 600V AC
Table B – Maximum DC Voltage and Amp. Ratings
For Bulletin 500LC Main Contacts (open or closed)
Load Type
Amperes Poles to Load
Load Type
Amperes
Continuous 2 in Series 3 in Series
General 20 125V DC 250V DC
Table C – Withstand Current Ratings
For Bulletin 500LC Lighting Contactors
(when applying to UL67 Listed Panelboard)
Available Symmetrical Amperes RMS
At AC
When Used with Molded–Case Circuit Breakers At AC
Service
Voltage
Withstand Current
Rating (amps)
Maximum Breaker Size
(amps)
250V 22,000 30
480V 14,000 30
600V 10,000 30
Catalog Number Explanation*
500LC– 12 0 0 A1
Number of
N/O Contacts
Number of
N/C Contacts
Enclosure
Type
Voltage Code
50/60 Hz
A1 = 110...120V
A2 = 208...240V
A3 = 265...277V
A4 = 347V
A5 = 440...480V
0 = open type
A = Type 1 surface mount
B = Type 1 flush mount
C = Type 4/4X surface mount
F = Type 12 surface mount
N = Type 3R surface mount
2 = 2 poles
3 = 3 poles
4 = 4 poles
6 = 6 poles
8 = 8 poles
10 = 10 poles
12 = 12 poles
0 = none
2 = 2 poles
3 = 3 poles
4 = 4 poles
6 = 6 poles
Example:
*Note: Contactor will accomodate a maximum of 12 contacts.
