Figure 18 Main Menu > Show/Set > Relay Relay Steps back one level
Main Settings GF-Res Settings RTD Settings
UNIT ID LINE 1 GF-RES TRIP LEVL RTD ENABLE
UNIT ID LINE 2 GF-RES TRIP DLAY RTD RESET MODE
PHASE ROTATION GF-RES WARN LEVL RTD1 LOCATION
RATED FREQ. GF-RES WARN DLAY RTD1 TYPE
DATE FORMAT Jam Settings RTD1 TRIP LEVEL
PHASE CT RATIO JAM TRIP LEVEL RTD1 WARN LEVEL
MOTOR FLA JAM TRIP DELAY RTD2 LOCATION
TWO SPEED ENABLE JAM WARN LEVEL RTD2 TYPE
CT RATIO-2 nd JAM WARN DELAY RTD2 TRIP LEVEL
MOTOR FLA-2 nd Undercurrent Set RTD2 WARN LEVEL
CORE B. CT RATIO UC TRIP LEVEL RTD3 LOCATION
PHASE VT RATIO UC TRIP DELAY RTD3 TYPE
LINE VOLTAGE UC WARN LEVEL RTD3 TRIP LEVEL
XFMER CONNECTION UC WARN DELAY RTD3 WARN LEVEL
Overload Set UC START INHIBIT RTD4 LOCATION
OVERLOAD ENABLE Current Imb Set RTD4 TYPE
OL RESET MODE CI TRIL LEVEL RTD4 TRIP LEVEL
OL RESET LEVEL CI TRIL DELAY RTD4 WARN LEVEL
SERVICE FACTOR CI WARN DELAY RTD5 LOCATION
MOTOR LRC CI WARN DELAY RTD5 TYPE
LOCKD ROTOR TIME Prot. Disable RTD5 TRIP LEVEL
ACCEL RACTOR PROT INHIBT TIME RTD5 WARN LEVEL
RUN STATE TIME K OL INHIBT TIME RTD6 LOCATION
MOTOR LRC-2 nd Start Monitoring RTD6 TYPE
MOTOR LRT-2 nd START MOTOR TIME RTD6 TRIP LEVEL
ACCEL FACT-2 nd Start-Delta Set RTD6 WARN LEVEL
RUN ST TC-2 nd STAR-DELTA ENABL RTD7 LOCATION
OL WARN LEVEL MAX STAR TIME RTD7 TYPE
START INH. LEVEL Start Inhibt RTD7 TRIP LEVEL
STOP COOL TIME STARTS/HR. RTD7 WARN LEVEL
OL RTD BIASING? MIN. OFF TIME RTD8 LOCATION
Short Ckt Set RESTART BLK TIME RTD8 TYPE
SC TRIP LEVEL Speed Sw Set RTD8 TRIP LEVEL
SC TRIP DELAY SS TRIP DELAY RTD8 WARN LEVEL
SC WARN LEVEL SS WARN DELAY RTD9 LOCATION
SC WARN LEVEL PTC Setting RTD9 TYPE
GF-CB Setting PTC ENABLE RTD9 TRIP LEVEL
GF-CB TRIP LEVEL PTC RESET MODE RTD9 WARN LEVEL
GF-CB TRIP DELAY RTD10 LOCATION
GF-CB WARN LEVEL RTD10 TYPE
GF-CB WARN DELAY RTD10 TRIP LEVEL
RTD10 WARN LEVEL
RTD11 LOCATION
RTD11 TYPE
RTD11 TRIP LEVEL
RTD11 WARN LEVEL
RTD12 LOCATION
RTD12 TYPE
RTD12 TRIP LEVEL
RTD12 WARN LEVEL
WIND TRIL VOTING
BEAR TRIP VOTING
TMP RTD BIASING?
