Quick Start Guide — Allen-Bradley Bulletin 825-P Modular Protection System
18
Trip Relay Assign
The 825-P allows mapping of only protection trip elements to the Trip output relay.
Settings are presented as bit-enumerated strings. The second line of the display
identifies a given bit’s associated function. To assign a function to the Trip relay,
simply program a value “1” in the bit location for each element you desire to assign
using the TRIP A through TRIP D settings. The front panel display appears as
follows:
TRIPA=10110000
OVERLOAD
Table F: Trip Relay Settings
Bit
0 1 2 3 4 5 6 7
TRIP A Overload Undercurrent Jam Current
Imbalance Short Circuit RTD - W/B PTC Ground Fault
(Res)
TRIP B VAR Underpower Under-
voltage Over-voltage Phase
Reversal
Power Factor Speed
Switch Ground Fault
(CB)
TRIP C Start Time Freq 1 Freq 2 RTD (Other) RTD
(Ambient) PTC Error RTD Error MCM Error
TRIP D Comm Idle Comm Loss Remote Trip Comm Fault Reserved Reserved Reserved Reserved
TIP
Make sure the Trip relay terminals (95, 96 and 98) are
labeled to correspond with the relay behavior setting
(Fail-Safe or Non-Fail-Safe).
