General specifications – Rockwell Automation 56RF High Frequency 13.56 MHz RFID EtherNet/IP Interface Block User Manual
Page 17
High Frequency 13.56 MHz RFID EtherNet/IP Interface Block 17
Drawing Number
10000181820 Ver. 01 - November 2012
General Specifications
Attributes
Value
Voltage, auxiliary power
(1)
(1)
Intended to be powered by a limited voltage, limited current supply.
24V DC (-20…+10%)
Auxiliary current per module, max.
(2)
(2)
A Listed or Recognized 4 A fuse shall be installed on the line side of the device.
4 A
Output current per RFID transceiver port, max.
100 mA @ 24V DC
Current for output device power per I/O port,
max.
0.5 A @ 30V
Current for input device power per I/O port,
max.
5 mA @ 30V
Communication rate
EtherNet/IP
10/100 Mbps
Full or half-duplex
100 meter per segment
LED indicators
Module Status - red/green
Network Status - red/green
Link Status - green/yellow
Auxiliary Power - green
I/O LED - yellow
Dimensions (HxWxD), approx.
179x37x43.25 mm (7.05x1.46x1.7 in.)
Weight, approx.
0.2 kg (0.45 lb)
Enclosure type rating
IP67 and IP69K
Wiring category
(3)
(3)
Use this Conductor Category information for planning conductor routing. Refer to publication
,
Industrial Automation Wiring and Grounding Guidelines.
1 - on signal ports
1 - on power ports
1 - on communications ports
