Rockwell Automation 1336S_E Drive Multipulse Bridge Assembly User Manual
Page 11
Multipulse Bridge Assembly Parts Kits
11
Table 7. VT Bridge Assemblies
1336 Variable Torque
Used with 12P ISO. XFMR
Used with 12P Auto XFMR
Used with 18P ISO. XFMR
Used with 18P Auto XFMR
Drive Size (HP)
AB Part Numbers
Bridge #
Bridge#
Bridge #
Bridge #
BX040V
301746
304976
301749
301743
B040V
301746
304976
301750
301743
BX060V
301746
304976
301750
301743
B060V
301746
304976
304247
301743
B075V
301746
304976
304247
301744
B100V
304250
304976
304247
301744
B125V
301747
304976
301751
301744
B150V
301747
304976
304249
301744
B200V
304245
304652
304249
301745
B250V
304245
304652
301752
301745
BP250V
304245
304652
301752
301745
BP300V
304246
304652
301753
301745
BP350V
301748
304652
301753
301745
BP400V
301748
304977
301235
304348
BX250V
304245
304652
301752
301745
B300V
304246
304652
301753
301745
B350V
301748
304652
301753
304348
B400V
301748
304977
301235
304348
B450V
301233
304977
301235
304348
B500V
301233
304977
301236
304348
B700V
301234
304978
301236
301231
B800V
301234
304978
301236
301231
