Total resistance values – Rockwell Automation 20P PowerFlex DC Drive - Frame B Pulse Transformer Circuit Board User Manual
Page 15

Rockwell Automation Publication 20P-IN009D-EN-P - February 2012
15
PowerFlex DC Drive Frame B Pulse Transformer Circuit Board
Total Resistance Values
Table 3 - 230V AC Input Drives
Table 4 - 460V AC Input Drives
3. Seal the TA potentiometer in place using RV (silicon).
Continue with Step 5:
Install the New Pulse Transformer Board and
Existing Switching Power Supply Board on page 17
.
Drive Current
Rating Code
DC
Amps
AC Line
Amps
HP
Set RTA Value Using TA
Potentiometer (Ohms)
146
146
119
40
12.575
180
180
147
50
10.2
218
218
178
60
8.422
265
265
217
75
6.928
360
360
294
100
5.1
434
434
355
125
4.23
Drive Current
Rating Code
DC
Amps
AC Line
Amps
HP
Set RTA Value Using TA
Potentiometer (Ohms)
167
167
136.4
100
10.994
207
207
169.1
125
8.87
250
250
204.3
150
7.344
330
330
269.6
200
5.564
412
412
336.6
250
4.456
