16
Check Advanced Options
to view the Survey Tool’s advanced configuration options.
Adjust Overlap and Sidelap
Overlap and sidelap are set to 50% and 60%, respectively,
by default. See page 35 for an in-depth discussion of these
parameters.
Adjust StartFrom
During the mission, you will maintain contact with the X8 through
the RC controller and ground station signals. If these signals are
lost during flight, the X8 will respond with the assigned failsafe
behaviors. See page 29. If your mission is likely to experience a
loss of signal, it is best practice to start from the corner of the
mission farthest from the launch point.
Configure Survey: Advanced Options
Camera Config
The options under the Camera Config tab
allow you to configure a camera other than
the SX260 and won’t be used for operating
the X8.
Survey Tool: Grid Options (Advanced) Select Grid Options
Mission Planner: Survey Tool
