3D Robotics RTF Y6 User Manual
Unfold arms and legs

Y6
Unfold arms and legs
travel position
Remove the bolts and thumb nuts outside the blue arms. Rotate
the blue arms into position, insert the bolts through the plates and
the arms, and secure the arms in place with the thumb nuts.
Rotate the legs into place and secure through the
inner hole with the provided bolt and nut.
remove
secure with bolts
flight position
rear arm
(black)
front arms
(blue)
slide arms into position
flight position
travel position
