Page 4

TESTING AFTER INSTALLATION Fig 4.

VOLuME CONTROL: The VOLUME CONTROL is used to turn on/off the

siren controller and adjust the volume. Turn the rotary control clockwise,

which will turn on the siren controller. Further clockwise rotation of the control

will increase the volume of all siren sounds and P.A system. The maximum

clockwise position of the control is determined by either feedback or squeal

being amplified. Adjust the rotary control to be positioned just before feedback occurs or to a sound level that is desired.
SELECTOR SWITCH: The rotary switch located in the center of the front panel is used to control six functions, which are:

five (5) different siren sounds and P.A..

13. Test each siren sound by positioning the selector control to the following positions:

• HI-LO: When the selector is in this position the siren produces a two-tone “HI-LO” sound that is continuous.
• WAIL: When the selector is in this position the siren produces a “WAILING” sound that is continuous.
• EURO: When the selector is in this position the siren produces a “EURO HI-LO” sound that is continuous.
• YELP: When the selector is in this position the siren produces a “YELP” sound that is continuous.
• PHASER: When the selector is in this position the siren produces a “PHASER” sound that is continuous
• MANUAL CONTROL SWITCH: The switch position allows the user to manually control two (2) siren sounds, AIR

HORN / SIREN. The manual control is located on the left side of the siren’s control panel. Lifting and holding the switch

activates the air horn sound. Pressing down and holding the switch will active a powerful siren. The manual switch will

also design to override any siren that is in use.

P.A. SYSTEM:

• Position the selector control to P.A. To test the P.A. system, depress the microphone’s push-to-talk button. Speak into the

microphone in a normal voice. The volume is controlled by the rotary control. The P.A. system will also override any siren

that is sounding.

SPECIFICATIONS: Siren controller

• 12-volt / 80 watts maximum output

• L 4-1/2 in.xDepth (front to back) 6-1/8 in.xH 1-3/8 in.

• Current 10 amperes volume control set at maximum

• Case is all metal black enamel painted

• Adjustable metal swing bracket provided

• LED Illuminated front control panel

• Noise canceling microphone

• Power harness is six-(6) ft. in length and has an inline fuse-holder

• Weight 2 lbs. (controller without swing bracket)

ANY EXPRESSED WARRANTY NOT PROVIDED HEREIN IS EXCLUDED AND DISCLAIMED. THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY LIMITED

TO A TERM OF THREE (3) MONTHS. UNDER NO CIRCUMSTANCES SHALL WOLO BE LIABLE TO PURCHASER OR

ANY OTHER PERSON FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES, WHETHER ARISING OUT OF BREACH

OF WARRANTY OR OTHERWISE.

To obtain warranty service, return the product prepaid, and include the original bill of sale showing the date of purchase.

Provide with the return a brief description of the problem. Also, include with the return a check or money order in the amount

of $10.00 to cover return shipping. Mail to:

Wolo Manufacturing Corp. One Saxwood Street, deer Park, NY 11729

Attn: Warranty Service E-mail: [email protected]

Cycle Rate

Wail – 20 cycles/min

Yelp – 120 cycles/min

Hi-Lo – 60 cycles/min

Phaser – 120 cycles/min

Warranty

Wolo Manufacturing Corporation (“Wolo”) warranties to the original purchaser, for three months from the

date of purchase, that this product is free from defects in workmanship and materials. If there is such a

proven defect, Wolo, at its option, will either repair or replace the item free of charge, if it is returned to Wolo

within three months from the date of purchase together with proof of purchase as described below. Wolo

reserves the right to inspect any defect prior to settling any warranty claim by repair or replacement. This

warranty is limited as above provided and Wolo will not be responsible for fire or other casualty or accident,

due to neglect, abuse, abnormal use, modifications, faulty installation of this product, or natural causes.
