UG:119 vicorpower.com Applications Engineering: 800 927.9474 Page 8
List of ConverterPACs used in the PFC MegaPAC-EL and
PFC MegaPAC-HPEL Low Noise and their features
ConverterPAC OVP OCP OTL RS/AS* LS/AS* PG TrimPot
QPAC (L) Std Std Std AS* AS* Opt Opt
DualQPAC (LD) N/A Std N/A AS* AS* Opt N/A
JuniorQPAC(LJ) N/A Std N/A AS* AS* Opt Opt
FinQPAC(PZL)+ Std Std Std AS* AS* Opt Opt
OVP Overvoltage Protection (latching) RS Remote Sense
OCP Overcurrent Protection (auto-recovery) LS Local Sense
OTL Overtemperature Limiting AS Autosense
PG Power Good (DC OK TTL Signal) + Maxi OTL is non-latching
*See Pages 11 and 12 for more information on Autosense.
Note: All ConverterPACs mentioned above can be paralleled EXCEPT the DualQPAC and JuniorQPAC.
Part Numbering
PFC MegaPAC-EL MPx
A
-7x
B
xxxx-x
C
-x
D
ex. MP5-782560-G-EL
PFC MegaPAC-HPEL MXx
A
-7x
B
xxxx-x
C
-x
D
ex. MX4-742543-2-EL
MP = MegaPAC prefix
x
A
= number of outputs
7 = power factor corrected
x
C
= optional code ex. G = RoHS
MX = PFC MegaPAC-HPEL prefix
X = PFC chassis that can use Maxi
x
B
= Number of modules
xxxx = assigned by Vicor
x
D
= optional code e.g. EL = Extended Length
