Table 4. Blower Coil and Plenum Dimensions (MAB16 through MAB80)
Optional Discharge Grille Plenum
Model
Nominal
CFM
Nominal
Capacity
(Tons)
Blower 2” Filter
Weight (lbs)
Height
(inches)
Grille Size
(inches)
MAB16 1600 4 10 x 10 (2) 20 x 25 75 23 16 x 24
MAB20 2000 5 10 x 10 (2) 20 x 25 75 23 16 x 24
MAB30 3000 7.5 15 x 15 (4) 16 x 25 90 26-1/2 18 x 48
MAB40 4000 10 15 x 15 (4) 16 x 25 90 26-1/2 18 x 48
MAB60 6000 15
MAB80 8000 20
(2) 15 x 12
(2) 16 x 20
(2) 16 x 25
(2) 20 x 20
(2) 20 x 25
240 36 (4) 12 x 30
Table 5. MAB Water Coil Connection Size (OD SWT)
4-Row 6-Row 2-Row
Model
Coil Size
Ship
Weight
(lbs)
Coil Size
Ship
Weight
(lbs)
Coil Size
Ship
Weight
(lbs)
MAB16 7/8" 321 1-1/8" 377 7/8" 30
MAB20 1-1/8" 344 1-1/8" 400 1-1/8" 34
MAB30 1-1/8" 584 1-3/8" 637 1-1/8" 49
MAB40 1-3/8" 584 1-5/8" 637 1-1/8" 53
MAB60 1-3/8" 844 1-5/8" 930 1-1/8" 86
MAB80 (2) 1-5/8" 890 (2) 1-5/8" 996 (2) 1-1/8" 106
Standard Installation
Basic installation procedure covers verifying and/or
installing the following items.
•
Ductwork
• Duct insulation and vapor proofing
• Unit placement
• Sound attenuation
• Condensate drain
• Water piping
• Motors and drives
• Electrical connections
Note: If mixing boxes form part of the unit, install the
mixing boxes prior to installing unit. See Mixing Box
installation instructions within this document.
Ductwork
Use accepted industry practices and design guidelines of
the ASHRAE Fundamentals Handbook. Ductwork must
comply with all building codes and the National Fire
Protection Association’s pamphlet 90A and 90B
Carefully inspect any previously installed ductwork to
determine suitability.
Note: Ductwork should be of a size meeting
requirements of the installation. Ductwork should
transition gradually from a smaller size blower
outlet to required duct run size to avoid excessive
loss of air velocity.
