6/8 profiles – Therma-Tru ARCH 2 Architectural Details - Book Size User Manual
Page 92
Architectural
Details
2.92
2014 (BOOK SIZE)
Arch 2
6/8 Profiles
6-9/16”
SECTION B-B
Scale: 3”
= 1’- 0”
SECTION C-C
Jacketed Urethane
Weatherstrip
Brickmould
6-9/16” Jamb
Foam Core
BTS
Lite Frame
Triple -Glazed
Decorative
Leaded Lite
Moisture-Resistant
End Rail
Scale: 3”
= 1’- 0”
7
” Composite
or Hardwood
-3/4
Sill
Top Rail
