6/8 classic-craft oak – Therma-Tru ARCH 2 Architectural Details - Book Size User Manual
Page 46
Architectural
Details
2.46
2014 (BOOK SIZE)
Arch 2
6/8 Classic-Craft Oak
SECTION B-B
Scale: 3”
= 1’- 0”
SECTION C-C
Jacketed Urethane
Weatherstrip
Oak Brickmould
Oak 4-9/16”
Jamb
Foam Core
4-9/16”
SMC Lite Frame
Triple-Glazed
Decorative
Leaded Lite
Moisture-Resistant
End Rail
Scale: 3”
= 1’- 0”
5-3/4
Sill
” Composite
or Hardwood
Top Rail
