Page 28
Architectural
Details
2.28
2014 (BOOK SIZE)
Arch 2
8/0 Classic-Craft American Style
Foam Core
SECTION B-B
Scale: 3”
= 1’- 0”
Jacketed Urethane
Weatherstrip
5-3/4
Sill
” Composite
or Hardwood
Dentil Shelf
Reinforcement
Block
Moisture-Resistant
End Rail
4-9/16”
Brickmould
4-9/16” Jamb
Triple-Glazed
Decorative
Leaded Lite
Top Rail
