Architectural
Details

Arch 2

2014 (BOOK SIZE)

2.61

6/8 Fiber-Classic Mahogany

SECTION A-A

Scale: 3”

= 1’- 0”

Single Door, Outswing

A

A

B

B

Scale: 3/4”

= 1’- 0”

Engineered Lumber Lock Stile Core
