Architectural
Details

2.18

2014 (BOOK SIZE)

Arch 2

8/0 Fiber-Classic/Smooth-Star Impact

Top Rail

Lock Stile

Bottom Rail

Door Bottom

Door Skin

Hinge Stile

Hinge Leaf

Impact Plate

Door Identification Marking (

Exploded View and Part Identification
