6/8 smooth-star raised panel – Therma-Tru ARCH 2 Architectural Details - Book Size User Manual
Page 78
Architectural
Details
2.78
2014 (BOOK SIZE)
Arch 2
6/8 Smooth-Star Raised Panel
SECTION B-B
Scale: 3
” = 1’- 0”
Jacketed Urethane
Weatherstrip
Brickmould
4-9/16” Jamb
5-3/4”Outswing Thermal
Break Bumper Sill
Foam Core
4-9/16”
BTS Lite
Frame
Triple-Glazed
Decorative
Leaded Lite
Moisture-Resistant
End Rail
SMC Decorative
Panel
Top Rail
