Architectural
Details

2.48

2014 (BOOK SIZE)

Arch 2

8/0 Classic-Craft Oak

SECTION B-B

Scale: 3

” = 1’- 0”

Jacketed Urethane

Weatherstrip

Brickmould

6-9/16” Jamb

Foam Core

6-9/16”

SMC Lite Frame

Moisture-Resistant

End Rail

7

” Composite

or Hardwood

-3/4

Sill

Top Rail
