Dimensional
Data

Arch 1

2014 (U1 REVISED)

1.69

8/0 Flush-Glazed Grille Locations

A

B

C

D

E

F

G

H

A

B

C

D

Panel

Glass A

B

C

D

2/0

14 x 80

9-3/8"

14-7/16"

10"

81-1/8"

2/6

21 x 80

8-7/8"

20-15/16"

10"

81-1/8"

2/8

21 x 80

10-7/8" 20-15/16"

10"

81-1/8"

2/10

25 x 80

10-7/8" 22-15/16"

10"

81-1/8"

3/0

25 x 80

12-7/8" 22-15/16"

10"

81-1/8"

GBG - Flush-Glazed - Fiber Classic - 8'0" Full Lite - 9 Lite Prairie

Panel

Glass A

B

C

D

2/0

14 x 80

9-3/8"

14-7/16"

10"

81-1/8"

2/6

21 x 80

8-7/8"

20-15/16"

10"

81-1/8"

2/8

21 x 80

10-7/8" 20-15/16"

10"

81-1/8"

2/10

25 x 80

10-7/8" 22-15/16"

10"

81-1/8"

3/0

25 x 80

12-7/8" 22-15/16"

10"

81-1/8"

GBG - Flush-Glazed - Smooth-Star - 8'0" Full Lite - 9 Lite Prairie

ůůĚŝŵĞŶƐŝŽŶƐƐŚŽǁŶĂƌĞƚŽƚŚĞĐĞŶƚĞƌŽĨƚŚĞŵƵŶƟŶ͘

Panel

Glass

A

B

C

D

E

F

G

H

2/6

21 x 80

14-7/8"

11-1/2"

18-1/4"

19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

2/8

21 x 80

15-7/8"

12-1/2"

19-1/4"

19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

2/10

25 x 80

16-7/8"

12-7/8" 20-15/16" 19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

3/0

25 x 80

17-7/8"

13-7/8" 21-15/16" 19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

Wood Grilles - Flush-Glazed - Fiber Classic - 8'0" Full Lite - 3W6H and 2W6H

Panel

Glass

A

B

C

D

E

F

G

H

2/6

21 x 80

14-7/8"

11-3/8"

18-3/8"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

2/8

21 x 80

15-7/8"

12-3/8"

19-3/8"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

2/10

25 x 80

16-7/8"

12-3/4"

21-1/16"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

3/0

25 x 80

17-7/8"

13-3/4"

22-1/16"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

GBG - Flush-Glazed - Fiber Classic - 8'0" Full Lite - 3W6H and 2W6H

Panel

Glass

A

B

C

D

E

F

G

H

2/6

21 x 80

14-7/8"

11-1/2"

18-1/4"

19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

2/8

21 x 80

15-7/8"

12-1/2"

19-1/4"

19-1/8"

32-3/8"

45-9/16"

58-3/4"

72"

2/10

25 x 80

16-7/8"

12-7/8" 20-15/16" 19-1/8"

32-5/16" 45-9/16"

58-3/4" 71-15/16"

3/0

25 x 80

17-7/8"

13-7/8" 21-15/16" 19-1/8"

32-5/16" 45-9/16"

58-3/4" 71-15/16"

Wood Grilles - Flush-Glazed - Smooth-Star - 8'0" Full Lite - 3W6H and 2W6H

Panel

Glass

A

B

C

D

E

F

G

H

2/6

21 x 80

14-7/8"

11-3/8"

18-3/8"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

2/8

21 x 80

15-7/8"

12-3/8"

19-3/8"

18-7/8"

32-1/4"

45-9/16"

58-7/8"

72-1/4"

2/10

25 x 80

16-7/8"

12-3/4"

21-1/16"

18-7/8"

32-3/16" 45-9/16"

58-7/8"

72-3/16"

3/0

25 x 80

17-7/8"

13-3/4"

22-1/16"

18-7/8"

32-3/16" 45-9/16"

58-7/8"

72-3/16"

GBG - Flush-Glazed - Smooth-Star - 8'0" Full Lite - 3W6H and 2W6H
