Dimensional
Data

1.46

2014 (U1 REVISED)

Arch 1

6/8 Lip Lite Grille Locations

A

D

A

B

C

D

Panel Glass

A

B

C

D

2/4

16 x 64

13-7/8"

-

-

37-3/16"

2/6

20 x 64

14-7/8"

-

-

37-1/8"

2/8

22 x 64

15-7/8"

-

-

37-1/8"

2/10

22 x 64

16-7/8"

-

-

37-1/8"

3/0

22 x 64

17-7/8"

-

-

37-1/8"

GBG - Lip Lite - 6'8" Full Lite -2W2H

Panel Glass

A

B

C

D

2/4

16 x 64

10-3/8"

17-7/16"

9-9/16"

64-5/8"

2/6

20 x 64

9-3/8"

20-7/16"

9-9/16"

64-5/8"

2/8

22 x 64

9-3/8"

22-7/16"

9-9/16"

64-5/8"

2/10

22 x 64

10-3/8"

23-7/16"

9-9/16"

64-5/8"

3/0

22 x 64

11-3/8"

24-7/16"

9-9/16"

64-5/8"

GBG - Lip Lite - 6'8" Full Lite - 9 Lite Prairie

ůůĚŝŵĞŶƐŝŽŶƐƐŚŽǁŶĂƌĞƚŽƚŚĞĐĞŶƚĞƌŽĨƚŚĞŵƵŶƟŶ͘
